Equipment
Coiling and decoiling
Decoilers
Floor-standing
HP-700
Floor-standing metal decoiler HP-700
Lightweight floor-standing decoiler MOBIPROF HP-700 designed for uncoiling rolls weighing up to 300 kg and up to 700 mm wide.
Specifications:
300 kg
Maximum load
700 mm
Coil width
any
Inner Ø of coil
On demand
Read more
HP-1250
Floor-standing metal decoiler НР-1250
Lightweight floor-standing decoiler HP-1250 designed for uncoiling rolls weighing up to 300 kg and up to 1 250 mm wide.
Specifications:
300 kg
Maximum load
1 250 mm
Coil width
any
Inner Ø of coil
On demand
Read more
Mobile
RM2S-625
Decoiler on wheels RM2S-625
Free movement of the decoiler is provided by four wheels with a brake. Self-centering mandrel for easy installation of coils.
Specifications:
2000 kg
Maximum load
625 mm
Coil width
400-580
Inner Ø of coil
On demand
Read more
RM2S
Decoiler on wheels with brakes RM2S
Free movement of the decoiler is provided by four wheels with a brake. Self-centering mandrel for easy installation of coils.
Specifications:
2000 kg
Maximum load
1250 mm
Coil width
400-580 mm
Inner Ø of coil
On demand
Read more
Double-support
RM-1250
Manual double-support coil decoiler RM-1250
To work with coils of different widths, the crosspieces can be set at any point of the shaft. To secure the roll, each special support on both crosspieces is expanded.
Specifications:
8 000 kg
Maximum load
1250 mm
Coil width
480-620 mm
Inner Ø of coil
On demand
Read more
RM-1500
Manual double-support coil decoiler RM-1500
To work with coils of different widths up to 1500 mm, the crosspieces can be set at any point of the shaft. To secure the roll, each special support on both crosspieces is expanded.
Specifications:
8 000 kg
Maximum load
1500 mm
Coil width
480-620 mm
Inner Ø of coil
On demand
Read more
RMSC-1250
Manual double-support decoiler RMSC-1250
Self centering coil holder is easy to install and fix inside of the metal coil. It is based on a two-bearing double-support frame.
Specifications:
8000 kg
Maximum load
1250 mm
Coil width
415-620
Inner Ø of coil
On demand
Read more
RMSC-1250E/NC
Double-support decoiler RMSC-1250E/NC
Motorized double-support decoiler RMSC-1250E/NC. Is equipped with a reversible gear motor, 220 V electric cabinet and a 3-button remote operation panel.
Specifications:
8000 kg
Maximum load
1250 mm
Coil width
415-620 mm
Inner Ø of coil
On demand
Read more
Self-lifting
RMS-1250
Self-lifting roll decoiler RMS-1250
The self-lifting mechanism of the metal decoiler allows using the decoiler both on industrial facilities, and on small construction sites where there are no lifting devices.
Specifications:
8000 kg
Maximum load
1250 mm
Coil width
480-620 mm
Inner Ø of coil
On demand
Read more
Open side
KR-2,0
Non-powered cantilever decoiler KR-2,0
Designed for uncoiling a metal strip coiled in a 2 000 kg roll and up to 350 mm wide. The Expanding of the support bars synchronously by rotation of the handwheel. Equipped with a system to prevent unwinding by inertia.
Specifications:
2000 kg
Maximum load
10-350 mm
Coil width
380-630 mm
Inner Ø of coil
On demand
Read more
KR-2,0 NC
Motorized cantilever decoiler KR-2,0 NC
Motorized cantilever decoiler KR-2,0-NC is designed for uncoiling a band up to 350 mm wide and a roll weighing up to 2 000 kg. Equipped with a non-contact sensor to control the sagging of the strip.
Specifications:
2000 kg
Maximum load
10-350 mm
Coil width
380-630 mm
Inner Ø of coil
On demand
Read more
KR-5,0
Powered cantilever decoiler KR-5,0
Powered cantilever decoiler KR-5,0 is designed for uncoiling up to 1250 mm wide and a coil weght up to 5 000 kg. Equipped with a non-contact sensor to control the sagging of the strip.
Specifications:
5000 kg
Maximum load
1250 mm
Coil width
480-630 mm
Inner Ø of coil
On demand
Read more
KR-7.5
Powered cantilever decoiler KR-7,5
Powered cantilever decoiler KR-7,5 is designed for uncoiling up to 1250 mm wide and a coil weght up to 7 500 kg.
Specifications:
7500 kg
Maximum load
1250 mm
Coil width
550-650 mm
Inner Ø of coil
On demand
Read more
KR-10
Powered cantilever decoiler KR-10
Powered cantilever decoiler KR-10 is designed for uncoiling up to 1250 mm wide and a coil weght up to 10 000 kg.
Specifications:
10 000 kg
Maximum load
1250 mm
Coil width
550-650
Inner Ø of coil
On demand
Read more
Metal sleeting
Sleeting and cutting machines
SPR-1250/3-R
Manual slitting machine SPR-1250/3R
Light manual cutting machine, useful slitting width 1250 mm, 0,7mm, manual transversal cut by extra roller shear.
Specifications:
5 m/min
Speed
0,35 - 0,8 mm
Soft steel thikness
up to 1250 mm
Max.coil width
On demand
Read more
SPR-1250/3-A
Light semi-electric slitting and cutting unit SPR-1250/3-A
Light semi-electric cutting machine, useful sleeting width 1250 mm, 0,7mm, electric uncoiling, manual transversal cut by extra roller shear.
Specifications:
6 m/min
Speed
0,35-0,8 mm
Soft steel thikness
1250 mm
Max. coil width
On demand
Read more
SPR-1250/5-A
Semi-electric slitting and cutting unit SPR-1250/5-A
Semi-electric slitting and cutting machine, useful slitting width 1250 mm, up to 1.5 mm, electric uncoiling, manual transversal cut by extra roller shear.
Specifications:
10 m/min
Speed
0,3-1,5 mm
Max. thickness
1250 mm
Max. coil width
On demand
Read more
SPR-1250/10-A
Semi-electric slitting and cutting unit SPR-1250/10-A
For slitting and length cutting of sheet and coiled metal. Electric uncoiling, 10 sets of disc cutters, manual transversal cut by extra roller shear.
Specifications:
10 m/min
Speed
0,35-1,5 mm
Soft steel thikness
1250 mm
Max. coil width
On demand
Read more
SPPR-1250/5-NC
Compact cutting line with automatic SPPR-1250/5-NC
Cutting and slitting line with a numerical control, as standart 5 sets of cutter blades, transversal roller shear.
Specifications:
10 m/min
Speed
0,35-1,5 mm
Soft steel capacity
1250 mm
Max. coil width
On demand
Read more
Profile production
Palisade Pales
Line for Metal Palisade Pales production
“Metal picket fence” series machines are designed for production of metal “Palisade Pales” wich is the main components of palisade fencing.
Specifications:
7 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
1.5 kW
Drive power, kW
On demand
Read more
Knauf profiles
Mobile line for CD and UD gypsum board profile production
Roll forming machines is designed for producing Knauf profiles, which are used to construct a metal frame to provide support for plasterboard panels.
Specifications:
20 m/min
Production speed
0,4-0,7 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
Gutter production
Gutter machines
Line is intended for production of a half-round or shaped gutters from thin-sheet galvanized steel 0,4-0,6 mm of thickness with plastisol or pural coatings. Gutter is one of the elements of the rain ware system responsible for draining rainwater and meltwater from the roofs of buildings.
Specifications:
10 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
3,7 kW
Drive power
On demand
Read more
Screed strip (spackling angle)
Line for producing screed strip (spackling angle)
Roll forming machine MCh-10х23.05 is designed to produced a “screed strip/spackling angle” profile used for plastering of surfaces.
Specifications:
10 m/min
Production speed
0,4-0,5 mm
Soft steel capacity
1,5 kW
Drive power
On demand
Read more
Plastering angle
Line for producing “Plastering angle” profile
Roll forming machine Mobiprof YP-23x23.1xR1.05 is designed for producing “Plastering angle” profile used for plastering of surfaces.
Specifications:
10 m/min
Production speed
0,4-0,5 mm
Soft steel capacity
1,5 kW
Drive power
On demand
Read more
Furring/omega profile
Omega channel rollforming machine
SPO roll forming machines are designed for production of omega- (furring) cannels.
Specifications:
15 m/min
Production speed
2,0 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
С- & U- chanels
С- or U- chanels roll forming machine
SPP and SPS series roll forming machines are designed for production of U- and C- channels from blancs required width or coiled strip with maximum thickness 2,0 mm.
Specifications:
10 m/min
Production speed
2,0 mm
Soft steel capacity
3,5 kW
Drive power
On demand
Read more
L- profile
Line for producing L- shaped profiles
YP series shaping machines are designed to produce L- shaped profiles (angles).
Specifications:
10 m/min
Production speed
2,0 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
Z- profile
Roll forming machine to produce Z- profile
ZP series shaping machines are designed to produce Z- shaped profile from galvanized steel сapacity up to 1.5 mm.
Specifications:
10 m/min
Production speed
0,5-1,5 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
Garden bed guarding
Garden bed guarding roll forming machine
Mobiprof SPS-225x20-80x80.05 roll forming machine is designed to produce C- chanel, which is used as a garden seedbed fences posts.
Specifications:
up to 15 m/min
Production speed
0,5 mm
Soft steel capacity
3,0 kW
Drive power
On demand
Read more
Wall panel
Wall panel machines
SO series roll forming machines are designed to produce metal siding from light gauge galvanized steel with polymer coating: polyester, plastisol.
Specifications:
10 m/min
Production speed
0,4-0,7 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
T- chanel
T- purlin roll forming machine
TP series roll forming machines are designed to produce T- channels.
Specifications:
10 m/min
Production speed
0,5-1,5 mm
Soft steel capacity
3,0 kW
Drive power
On demand
Read more
Heat spreading plate
Line for heat spreading plate shapes
The machine is intended for profiling heat spreading plates applied for construction of heating floor.
Specifications:
7 m/min
Production speed
0,4-0,8 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Drift eliminator
Drift eliminator roll former
Roll forming machine VlnP.R19-39x205.Зv.07 is intended for profiling of “Drift eliminator” profile from thin-sheet galvanized steel up to 0,7 mm of thickness.
Specifications:
10 m/min
Production speed
0,45-0,7 mm
Soft steel capacity
3,0 kW
Drive power
On demand
Read more
Ridge cap
Ridge cap roll former
The machines are designed for producing “ridge cap” or “neck cap” profiles of 0.4 to 0.6 mm steel with different types of polymer coating.
Specifications:
7 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
1,5 kW
Drive power
On demand
Read more
Flat hem roll former Zv-0,5
Zv-0,5 Flat hem roll former
Roll forming machine is intended for rolling of edges from thin-sheet galvanized steel 0,4-0,5 mm of thickness. Rolling is proceed in two passes - first one side, then the other.
Specifications:
6 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Flat hem roll former Zv.R
Zv.R Flat hem roll former
Dual sided hemming machine is intended for rolling of edges in a single pass from thin-sheet galvanized steel 0,4-0,5 mm of thickness. The machine with stepless width adjustment from 90 mm to 690 mm conveniently via handwheel.
Specifications:
7 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Fencing blinds
“Fencing blinds” roll former
“Fencing blinds” profile roll forming machine is intended to produce metall profile (lamellas) used for “Blinds” type fence construction.
Specifications:
10 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
3,0 kW
Drive power
On demand
Read more
Window trim
Window trim roll former
PK series shaping machines are designed for production of “Window trim” profile made of coiled galvanized steel or steel with polymer coating, 0.4 to 0.6 mm thick. The shape rolling is performed in two passes - one side at a time.
Specifications:
6,5 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Window drip cap
Roll forming machine for "Window drip cap" profile
PK.R series roll forming machines are equiped with stepless width adjustment and the machines are intended for profiling “Window drip cap” profile in a single pass.
Specifications:
7 m/min
Production speed
0,4-0,8 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Decorative cover
Roll froming machine for decorative profile “Cover”
The machine produces decorative profile “Cover” which is used for covering the aluminium clamping shape of glass structures.
Specifications:
10 m/min
Production speed
0,7 mm
Soft steel capacity
2,2
Drive power
On demand
Read more
Shaped rings CUU-74.10
Shaped rings roll forming machine
MOBIPROF CUU15х18-74.10 roll forming machine is designed to produce metal shaped rings from galvanized steel сapacity up to 1,0 mm.
Specifications:
10 m/min
Production speed
1,0 mm
Soft steel capacity
0,75 kW
Drive power
On demand
Read more
Shaped rings CUU-K420
Shaped rings roll forming machine CUU-K420
CUU-K420 roll forming machine is designed to produce metal "shaped rings" profile wich is used as garbage chute of cylindrical channel of the Sandwich-type.
Specifications:
10 m/min
Production speed
1,5 mm
Soft steel capacity
up to 6 kW
Drive power
On demand
Read more
Metall plate lining
Metall plate lining roll former
Metal plate lining roll forming machine is intend to produce “metal cover” profile which is used for production “Sandwich” type panels.
Specifications:
6 m/min
Production speed
0,4-0,7 mm
Soft steel capacity
1200 mm
Infeed width
On demand
Read more
Curtain rod blinds
Curtain rod blinds roll former
Roll forming machines for “Curtain rod blinds " profile, for production of special shapes applied in design of horizontal aluminium blinds.
Specifications:
10 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
1,5 kW
Drive power
On demand
Read more
PVC windows reinforcements
Pvc windows reinforcements
The line is intended for profiling of open and closed profiles for armoring of items from PVC from thin-sheet of galvanized steel 1,5-2,0 mm of thickness.
Specifications:
10 m/min
Production speed
1,0-2,0 mm
Soft steel capacity
2,2 kW
Drive power
On demand
Read more
Growing gutter
Line for growing gutter production
TL series roll forming machines for producing growing gutter shapes, applied in a greenhouse facility for growing crops using hydroponics technology.
Specifications:
10 m/min
Production speed
0,7 mm
Soft steel capacity
3,0 kW
Drive power
On demand
Read more
Metal folding
Folding machines
Manual
LTB-2000/0,8
Folding machine LTB-2000/0,8
Is designed for manufacturing the whole range of products for building roof and faces made of up to 0.8 mm steel.
Specifications:
2040 mm
Folding length
0,8 mm
Capacity zinc / steel
155°
Max folding angel
On demand
Read more
LTB-2500/0,8
Folding machine LTB-2500/0,8
Is designed for manufacturing the whole range of products for building roof and faces made of up to 0.8 mm steel.
Specifications:
2540 mm
Folding length
0,8 mm
Capacity zinc / steel
155°
Max folding angel
On demand
Read more
Мetal roofing production
Standing Seam Roof Machines
SFP-700
Double standing seam machine SFP-700
It has high versatility and mobility. Produces roofing panels with both single and double standing seam at the job site.
Specifications:
250-700 mm
Infeed width
0.45-0.7 mm
Galvanized steel
25 mm
Lock height
On demand
Read more
SFP-700 LITE
Double standing seam machine SFP-700 LITE
The budget version of the roofing machine SFP-700, is popular with professional roofers for many years. The machine does not have the 6th сalibration mill stand.
Specifications:
250-700 mm
Infeed width
0,45 - 0,7 mm
Galvanized steel
25 mm
Lock height
On demand
Read more
SFP-700 KOMPACT
Standing seam roll forming machine SFP-700 KOMPACT
Mobile, compact and lightweight, suitable for frequent relocations. Produces roofing panels with both single and double standing seam at the job site.
On demand
Read more
SFPR
Standing seam machine SFPR
The machine with stepless width adjustment from 320 mm to 700 mm conveniently via handwheel. SFPR allows to produce high quality roof panels with double or single standing seam
Specifications:
320-700 mm
Infeed width
0,45 - 0,7 mm
Galvanized steel
25 mm
Lock height
On demand
Read more
SFPR-NC
Standing seam roll forming machine SFPR-NC
Standing seam roll forming machine SFPR-NC with numerical control produces roofing panels with both single and double standing seam at the job site.
Specifications:
250-250 mm
Infeed width
0,45 - 0,6 mm
Galvanized steel
25 mm
Lock height
On demand
Read more
SFP-1250
Standing seam rollforming machine SFP-1250
Universal machine for onsite work to produce double standing seam profiles 25 from blanks or cut lengths in a single pass with width 1250 mm.
Specifications:
1250 mm
Infeed width
0,45 - 0,7 mm
Galvanized steel
25 mm
Lock height
On demand
Read more
SFPZ
Snap lock roll forming machine SFPZ
Produces roofing panels with single snap lock seam, the distinctive features of which are simple and quick installation of the panel without the use of special tools, hidden mounting system, allow for thermal expansion of the material.
Specifications:
250 - 625 mm
Infeed width
0,5 - 0,7 mm
Galvanized steel
32 mm
Lock height
On demand
Read more
Standing seaming tool
Set of hand seamers
Set of hand seamers
The steel lock hand seamer manufactured by MOBIPROF are designed for closing of double standing seam one by one in two steps.
Specifications:
0,4-0,7 mm
Max. thickness
25 mm
Lock height
220 mm
Size
On demand
Read more
Hand Seamer with bronze plates
Hand seaming tool with bronze plates and seam hooks
Hand tool with bronze plates and seam hooks. It is optimal for work on metal with polymeric coating and copper.
Specifications:
0,4-0,6 mm
Max. thickness
25 mm
Lock height
220 mm
Size
On demand
Read more
Semi-automatic seaming tool
Semi-automatic seaming tool
Semi-automatic seaming tool used for closing locks on a double standing seam roofing panels.
Specifications:
0,4-0,6 m
Max. thickness
25 mm
Lock height
5,5 kg
Weight
On demand
Read more
Power seamer FZM
Seaming machine FZM
Universal seaming machine unit FZM for seaming angular and double standing seams with a single pass.
Specifications:
0,45-0,7 mm
Galvanized steel
25 mm
Lock height
5 m/min
Operating speed, m/min
On demand
Read more
Rain water system
Swaging-beading machine
ZRM-0,8
Manual swaging-beading machines ZRM-0,8
Flanging, crimping, rolling rifts. Manual drive, 4 pairs of rollers.
Specifications:
0,8 mm
Capacity Steel S235JR
50 mm
Vertical distance
180 mm
Throat depth
On demand
Read more
ZEM-0,8
Electric swaging-beading machine ZEM-0,8
Flanging, crimping, rolling rifts. Reversible electric drive control by simple pedal, 4 pairs of rollers.
Specifications:
0,8 mm
Capacity Steel S235JR
50 mm
Vertical distance
180 mm
Throat depth
On demand
Read more
Lock sem closing machine
FOS.R-1300/0,8
Lock sem closing machine FOS.R-1300/0,8
Is designed to lock sem closing machine during production of air ducts and rain water systems.
Specifications:
0,8 mm
Max. sheet thikness
1300 mm
Operation length
2500 mm
Max. length of workpiece
On demand
Read more
FOS-1300/0,8
Lock sem closing machine FOS-1300/0,8
Is designed to lock sem closing machine during production of air ducts and rain water systems. Reversible electric drive control by simple pedal.
Specifications:
0,8 mm
Max. sheet thikness
1300 mm
Operation length
2500 mm
Max. length of workpiece
On demand
Read more
Gutter
Gutter production
Gutter forming machine
Equipment is intended for production of a gutter from thin-sheet galvanized steel 0,4-0,6 mm of thickness with plastisol or pural coatings. Gutter is one of the elements of the rain ware system responsible for draining rainwater and meltwater from the roofs of buildings.
Specifications:
10 m/min
Production speed
0,4-0,6 mm
Soft steel capacity
3,7 kW
Drive power
On demand
Read more
Custom made Machinery
Menu
About
Info
Delivery
Contacts
Home
Rain water system
Gutter
Gutter production

Gutter forming machine

Price on request

Gutter production

Price on request
array(0) {
}

Description
Advantages
Specifications
Standard and options
Description

Gutter roll forming machine is intended to produce of a gutter from thin-sheet galvanized steel 0,4-0,6 mm of thickness with plastisol or pural coatings. Gutter is one of the elements of the rain ware system responsible for draining rainwater and meltwater from the roofs of buildings.

Gutter forming machine can operate in semi-automatic and automatic mode. In semi-automatic mode operator should press “Start” button and provide feeding of specific cut length blanks into the machine. In the automatic mode, the line shall comprise a band decoiler for feeding metal into the machine, a device for cutting the profiles into specific cut lengths and numeric control system. Our numeric control with touchpad has a user-friendly interface with various controlled parameters. The system is also equipped with alarm and error indicators and support information as well as maintenance service information.

To get a quotation of the equipment you should write us by e-mail: info@mobiprof.ru or call us.

A custom build roll forming machine based on the customer’s drawings can be manufactured.

Print

Advantages
  • calibration mill stand for fine-adjustment for necessary thickness and metal type;
  • heavy duty bearing supports;
  • adjustable entry guides;
  • unlimited length of produced shapes;
  • simplicity and reliability of process design;
  • light weight and small dimensions of the machine.

Print

Specifications
Production speed, mm up to 10
Soft steel thickness S235JR, mm 0,4-0,6
Drive power, kW 3,7
Supply voltage, V 380 (220 NC)
Dimensions, LхWхH, mm 3400x550x1200
Weight, kg 800

Print

Standard and options
Gutter forming machine
The machine is in the basic configuration, without additional equipment.
Options
Numeric control with touch screen (NC)
Numeric control with touch screen (NC)
Hydraulic powered guillotine GS
Hydraulic powered guillotine GS
Variable-frequency inverter
For single-phase (220V) operation.

Print

Types of profiles
Strip width
250 мм

Profile width
75х134 мм
GT-75х134.06
Strip width
302 mm

Profile width
95х126 mm
GT-95х126.06
Geography of supplies
Coiling and decoiling
Decoilers
Metal sleeting
Sleeting and cutting machines
Profile production
Screed strip (spackling angle)
Plastering angle
Palisade Pales
All equipment
Metal folding
Folding machines
Мetal roofing production
Standing Seam Roof Machines
Standing seaming tool
Rain water system
Swaging-beading machine
Lock sem closing machine
Gutter
Legal address:
115054, Moscow, st. Dubininskaya, 69
Production address
142103, Moscow region, Podolsk, st. Roschinskaya, 22
INN: 772501001
KPP: 7725850431
OKPO: 40276717
JSC Raiffeisenbank Moscow
INN: 772501001
KPP: 7725850431
OKPO: 40276717
Contact phone numbers:
8 (800) 333-41-10
8 (495) 966-18-90

Business hours:
Mon.-Fri.: 9:00-17:00
© 1995-2024 MOBIPROF. All rights reserved.
Report about any noticed errors to info@mobiprof.ru. When copying any materials the reference to website www.mobiprof.ru is mandatory. The goods specifications may differ, request the goods specifications at the time of purchase and payment. All information on the website is for reference only and is not a public offer in accordance with item 2, article 437 of the Civil Code of the Russian Federation.

Our website uses cookies to ensure its functionality and improve the quality of service. You automatically agree to the use of these technologies by continuing to use our site. Details in the privacy policy.
